Flexible Soft Modules
Entertainment center, e-commerce live broadcast room, radio and television studio, indoor conference room, science and technology exhibition hall and other application places
- Commodity name： Flexible Soft Modules
Keyword:
Flexible Soft Modules
- PRODUCT DESCRIPTION
-
*Flexible Module Series
Model/Type P1.25 P1.53 P1.86 P2 P2.5 P3 P4 Pixel Configuration 1R1G1B Pixel Pitch 1.25mm 1.53mm 1.86mm 2mm 2.5mm 3mm 4mm Pixel Density (Dots/m²) 640000 422500 288400 250000 160000 105625 62500 Lamp size SMD1212 SMD1212 SMD1515 SMD1515 SMD2121 SMD2121 SMD2121 Structural Features LED and Driver Integrated Design Driving Method(Constant Current Drive) 1/64s 1/52s 1/43s 1/40s 1/32s 1/26s 1/20s Module Size 320*160mm Module Resolution (Dots) 256*128=32768 208*104=21632 172*86=14792 160*80=12800 128*64=8192 104*52=5408 64*32=2048 Box material cabinet is customized according to customer requirements. White Balance Brightness ≥500cd/m² ≥500cd/m² Brightness Uniformity Brightness Difference Between Pixels ±2.5% Optimal Viewing Distance 1.5-100m 1.5-100m 1.8-100m 2-100m 2.5-100m 2.5-100m 2.5-100m Optimal Viewing Angle Horizontal viewing Angle 120±10°，
Vertical viewing Angle120±10°Screen Thickness ≤100cm Screen Weight Based on customized structures Operating Voltage AC110v~240V (50~60Hz) Average Power Consumption 300w/m² Maximum Power Consumption 600w/m² Driving Device High Refresh Rate IC High Refresh Rate IC High Refresh Rate IC High Refresh Rate IC ICN2038S/FM6124/DP5125 Standard Refresh Rate IC Standard Refresh Rate IC Gray level 256RGB,total 65536 Display Color 16.7M Grayscale Calibration Software-Adjustable 100-Level Grayscale Frame Rate ≥60Hz Refresh Rate ≥3840Hz ≥1920Hz/≥3840Hz LED Lifespan ≥100,000 hours Mean Trouble-Free Operation Time ≥10,000 hours Operating temperature range (℃) -40~50℃ Storage temperature range (° C) -50~85℃ Operating Environment Indoor
Honor&Certification
Get A Quote
Note: Please leave your email address, our professionals will contact you as soon as possible!
