Indoor Full Color Modules
Interior decoration, stage performances, indoor monitoring, conference venues, exhibition halls, medical centers, catering, chain brands, indoor displays and other fields
- Commodity name： Indoor Full Color Modules
Keyword:
Indoor Full Color Modules
- PRODUCT DESCRIPTION
-
Model/Type P2 P2.5 P3.076 P4 P5 Pixel Configuration 1R1G1B Pixel Pitch 2mm 2.5mm 3.076mm 4mm 5mm Pixel Density (Dots/m²) 250000 160000 105625 62500 40000 Lamp size SMD1515 SMD2121/1515 SMD2121 SMD2020 SMD2121 Structural Features LED and Driver Integrated Design Driving Method(Constant Current Drive) 1/40s 1/32s 1/26/52s 1/32s
1/20s1/16s Module Size 320*160mm 320*160mm 320*160mm 256*128mm
256*256mm
320*160mm320*160*15mm Module Resolution (Dots) 160*80=12800 128**64=8192 104*52=5408 64*32=2048
64*64=4096
80*40=320064*32=2048 Box material 640*480mm Die-cast aluminum case customization 640*480mm Die-cast
aluminum caseWhite Balance Brightness 450cd/m²-600cd/m² Brightness Uniformity Brightness Difference Between Pixels ±2.5% Optimal Viewing Distance 1-30m 2.5-100m 2.5-100m 4-100m 5-100m Optimal Viewing Angle Horizontal viewing Angle 120±10°，
Vertical viewing Angle120±10°Screen Thickness ≤100cm Screen Weight ≤35kg/m² ≤15kg/m² Operating Voltage AC110v~240V (50~60Hz) Average Power Consumption 300w/m² 400w/m² Maximum Power Consumption 600w/m² 800w/m² Gray level 256RGB,total 65536 Display Color 16.7M Grayscale Calibration Software-Adjustable 100-Level Grayscale Frame Rate ≥60Hz Refresh Rate ≥3840Hz ≥1920Hz/≥3840Hz ≥1920Hz/≥3840Hz ≥1920Hz/≥3840Hz ≥1920Hz/≥3840Hz LED Lifespan ≥100,000 hours Mean Trouble-Free Operation Time ≥10,000 hours Operating temperature range (℃) -40~50℃ Storage temperature range (° C) -50~85℃ Relative Humidity (RH) 10%~95%RH Operating Environment Indoor *INDOOR DISPLAY HIGH BRIGHTNESS
*INDOOR MODULE FEATURES
*INDOOR FIXED SCREEN
